MS-H-ProA

Features

Digital control with max. temperature at 340ºC,max speed up to 1500rpm.
Aluminum alloy work plate with flat plane provides fast heating perfermance, and strong compatibility with various heating containers and heating blocks.
High-resolution LCD display shows actual temperatures and speed.
PID controller ensures a precise and steady heating process.
External temperature control is possible by connecting the temperature sensor(PT 1000) with accuracy at ±0.2°C.
Brushless DC motor enables more powerful speed control.
Three heating modes for selected ( fast heating, standard heating and stable heating )
Remote control function through RS232 interface provides PC control and data transmission.

Specifications

Work Plate Dimension	f135mm(5inch)
Work plate material	Aluminium
Motor type	Brushless DC Motor
Heating temperature range	Room temp.-340ºC, increment 1ºC
Temperature display accuracy	±0.1ºC
Heating power	600W
Speed range	100-1500rpm resolution±1rpm
Max. stirring quantity[H2O]	20L
Speed Display	LCD
Temperature display	LCD
