MS7-H550 Pro

Features

LCD display for precise monitoring of speed and temperature
Built-in PID controller ensures safe heating of the medium with overheating protection
Max. heating plate temperature 550°C
Glass ceramic work plate provides excellent chemical resistant performance and most efficient heat transfer
External temperature control is possible by connecting the temperature sensor(PT1000) with an accuracy at ±0.2°C
Digital speed controlling, max. speed at 1500rpm
Outstanding brushless DC motor enables more stirring power
Two rotating knobs enable easy adjustment of speed and temperature
The “HOT” warning will flash when the work plate temperature is above 50°C even when the hotplate is turned off
Remote function provides PC control and data transmission

Specifications

Work Plate Dimension	184x184mm (7 inch)
Work plate material	Glass Ceramic
Motor type	Brushless DC Motor
Heating temperature range	Room Temp.-550°C,increment 1°C
Temperature display accuracy	±0.1°C
Heating power	1000W
Speed range	100-1500rpm resolution ±1rpm
Max. stirring quantity[H2O]	20L
Speed Display	LCD
Temperature display	LCD
