DM-0412P

Features

Max. speed 4500rpm;
Rotor speed can be set in RPM/RCF;
3 preloaded programs for fast operation of PRP/PRF/CGF application;
9 programs for customization can be stored in memory;
Powerful CPU for easy operation of speed, time and all other parameters;
Easy-to-read processing display and sound alert;
Automatic lid-lock release after running;
Conforms to international safety standards and regulations marked with CE, cTUVus and FCC, and passed the explosion-proof test / MCA test according to IEC/EN61010-2-20;
Passed EN61010-2-101: 2 0 0 2 particular requirements for In-Vitro diagnostic (IVD) medical equipment;
Maintenance-free brushless DC motor.

Specifications

Speed range	300-4500rpm,increment: 10rpm
Max. RCF	2490xg, increment: 10g
Speed accuracy	±10rpm
Rotor	8x15ml,12x10mL/7mL/5mL
Run time	30sec-99min
Motor	Brushless DC motor
Display	LCD
Program	PRP:3480rpm, 5mins, PRF:2690rpm, 7mins, CGF: Step1 2700rpm 2mins, Step2 2400rpm 4mins Step3 2700rpm 4mins, Step4 3000rpm 3mins,
Safety Features	Door interlock,Overspeed detector; Automatic internal diagnosis
