| Functions | Heating & Cooling |
| Temperature Range | Heating: room temp. - 110°C Cooling: room temp. - below room temp. 25°C |
| Temperature Control Accuracy | ± 0.5°C |
| Max. Heating Rate | 5.5°C/min |
| Max. Cooling Rate | 2.5°C /min(100°C-room temp.) and 0.5°C/min(below room temp.) |
| Mixing Orbit | 3mm |
| Overheating Protection | 150°C |
| Adapter Block Material | Aluminium |
| Power | 200W |
| Dimension [D×W×H] ( without the heating block ) | 200×235×120mm |
