Principle	Electrical resistance for counting, cyanide free method for hemoglobin
Sample Consumption	Venous mode: 9.6μL, Capillary mode: 9.6μL, Pre-diluted mode: 20μL
Working Mode	Double passages counting detection + independent HGB measurement system; 24 hours with auto standby
Operation Mode	USB keyboard & mouse (PE-6000Plus: Touch screen)
Throughput	≥60 samples/hour
Storage	50,000 sample results inclusive of the histograms
QC Mode	L-J QC mode
Reference Value	Baby, Kid, Woman, Man, Normal and Customization
Cross Contamination Ratio	WBC/RBC/HGB﹤0.5%, PLT﹤1%
Interface	4×USB, 1×ethernet, 1×VGA (for external monitor)
Printer	Built-in thermal recorder, optional external printer, eight report formats
Environment Requirement	Temperature: 15℃~35℃; Humidity: 10%-90%
Parameters	3-part differential of WBC; 20 parameters (WBC, LYM#, MID#, GRAN#, LYM%, MID%, GRAN%, RBC, HGB, HCT, MCV, MCH, MCHC, RDW-SD, RDW-CV, PLT, MPV, PDW, PCT, P-LCR) + 3 color histograms (WBC/RBC/PLT)

Principle	23 parameters+8 Research parameters +4 scatter diagrams and 3 histograms: WBC/RBC/PLT; 5 Diff of WBC
Sample Volume	Venous Mode/Capillary Mode/Pre-diluted Mode≤20μL
Operation Mode	Touch screen operation, also support USB keyboard & mouse; Based on Linux system
Throughput	60 samples/h, 24 hours work with auto standby
Storage	50,000 sample results inclusive of the histograms
Application	Baby/kid/women/man/normal/customized
Quality control	L-J; X-B
Display	10.4'' touch screen
Language	Multi-Language supported, user can on-line switch interface language
Calibration mode	Manual calibration and auto calibration
Weight	26.5KG
Dimension	364×498×431(mm)
Working environment	Temperature: 10-30℃, Humidity≤70%
Test mode	CBC+DIFF, CBC
